LAMPS AND SPEAKER HOUSINGS, ULTRA TOUR-PAK - FLHTCUTG

SCREW NO. 10-16 X 1/2 TORX PAN HD., SELF-TAPPING

WELL NUT

CRIMP NUT

WASHER 1/2 X 13/16 X 1/32

WASHER 1/4 X 7/16 X 1/32

NUT WITH LOCKWASHER

CABLE STRAP

CABLE STRAP

HOUSING 16-WAY SOCKET (BLACK)

TERMINAL SOCKET, 18-20 AWG

TERMINAL PIN, 16-20 AWG

HOUSING SIX-WAY PIN (BLACK)

TERMINAL SOCKET, 16-20 AWG

TERMINAL SOCKET, 1/4 IN

SEAL PIN

SEAL 18-20 AWG (WHITE)

HOUSING TWO-WAY PIN

SOCKET HOUSING TWO-WAY (WHITE)

TERMINAL PIN, 16-20 AWG

TERMINAL SOCKET, 16-20 AWG

RETAINER ANCHORED

Гайка

ANTENNA MAST AM/FM/WB/LW

SCREW NO. 6-32 X 3/4 TORX PAN HD. (BLACK ZINC)

SCREW NO. 8-16 X 9/16 TORX PAN HD. (ZINC)

GROMMET SPEAKER (RIGHT)

GROMMET SPEAKER (LEFT)

Заглушка

LAMP TOUR-PAK, WITH 76000164, 76000165, 76000186 AND 76000208 (DOMESTIC)

WIRING HARNESS TOUR-PAK, WITH 10065, 72169-07, 72188-07BK, 72213-94, 72610-08, 73102-96BK, 73152-96WE, 73190-96, 73191-96, 69200210, 69200211, 69200225 AND 69200226

WIRING HARNESS AM/FM GROUND JUMPER, WITH 72290-94

WIRING HARNESS SPEAKER, WITH 10065 AND 72168-07 (LEFT)

WIRING HARNESS SPEAKER, WITH 10065, 72168-07 AND 71400005 (RIGHT)

CABLE EXTENSION AM/FM ANTENNA

CABLE EXTENSION CB ANTENNA

SOCKET CONNECTOR FIVE-WAY (BLACK)

SECONDARY LOCK FIVE-WAY (BLACK)

WEATHER CAP ASSEMBLY

SWITCH ASSEMBLY REAR SPEAKER, WITH 72168-07, 71400006 AND 71400007

KNOB PUSH TO TALK (PTT) VOL-/VOL+ REAR CONTROL SWITCH

KNOB MODE SELECT UP/DOWN REAR CONTROL SWITCH

GRILLE REAR SPEAKER

SPEAKER 5.25 IN

SPEAKER BOX ENCLOSURE RIGHT REAR

SPEAKER BOX ENCLOSURE LEFT REAR

STUD ANTENNA

SET SCREW ANTENNA, M5 X 43 MM

BEZEL SPEAKER SWITCH

STUD ANTENNA

PLUG ASSEMBLY ANTENNA
