CRANKCASE - GEAR SIDE

Палец

PLUG, crankcase

PLUG, oil screen

SCREW, No. 8-32 X 1/2 Pozidrivflat ctsk. hd. (Grade 2 steel)

SCREW, 1/4-20 X 1-1/4 knurled socket hd. (w/lockpatch)

BOLT, 5/16-18 X 1 hex. hd.(Grade 5 steel)

SCREW, 1/4-20 X 1-3/4 knurled socket hd. (Grade 8 steel)

SCREW, 1/4-20 X 1-3/8 knurled socket hd. (w/lockpatch)

SCREW, 1/4-20 X 1-1/8 knurled socket hd. (w/lockpatch)

SPACER, exhaust pipe bracket (Late 80 - FLT,)

WASHER, 1/4 X 7/16 X 1/16

WASHER, No. 8 X 7/16 X 3/64

Шайба

WASHER, 5/16 X 11/16 X 1/16

LOCKWASHER, 5/16

RIVET, ignition cover

NEEDLE BEARING crankcase cam cover

CLAMP, circuit breaker wire

RETAINING RING, oil pump drive shaft

Уплотнительное кольцо

KEY, gear shaft

NUT, gear shaft

PINION GEAR, 1.4751-56 pitch dia. (orange)

PINION GEAR, 1.4745-51 pitch dia. (white)

PINION GEAR, 1.4737-45 pitch dla. (yellow)

PINION GEAR, 1.4729-37 pitch dia. (red)

PINION GEAR, 1.4721-29 pitch dia. (blue)

PINION GEAR, 1.4715-21 pitch dia. (green)

PINION GEAR, 1.4710-15 pitch dia. (black)

FITTING, 90 degree

Фитинг

CAM AND PINION GEAR SET

BUSHING, oil pump shaft

SPACER, gear shaft pinion

OIL SCREEN, crankcase

SPRING, oil screen

GEAR COVER

GASKET gear cover

GEAR COVER ASSEMBLY

BREATHER VALVE GEAR | NOTE: Order plastic washers only with plastic breather valve, DO NOT intermix steel and plastic parts.

THRUST WASHER, breather valve - 0.11 thick (80 to Early 82 - FLT, Classic) | NOTE: Order plastic washers only with plastic breather valve, DO NOT intermix steel and plastic parts.

THRUST WASHER, breather valve - 0.115 thick (80 to Early 82 - FLT, Classic) | NOTE: Order plastic washers only with plastic breather valve, DO NOT intermix steel and plastic parts.

THRUST WASHER, breather valve - 0.12 thick (80 to Early 82 - FLT, Classic) | NOTE: Order plastic washers only with plastic breather valve, DO NOT intermix steel and plastic parts.

THRUST WASHER, breather valve - 0.125 thick (80 to Early 82 - FLT, Classic) | NOTE: Order plastic washers only with plastic breather valve, DO NOT intermix steel and plastic parts.

THRUST WASHER, breather valve - 0.13 thick (80 to Early 82 - FLT, Classic) | NOTE: Order plastic washers only with plastic breather valve, DO NOT intermix steel and plastic parts.

THRUST WASHER, breather valve - 0.135 thick (80 to Early 82 - FLT, Classic) | NOTE: Order plastic washers only with plastic breather valve, DO NOT intermix steel and plastic parts.

THRUST WASHER, breather valve - 0.14 thick (80 to Early 82 - FLT, Classic) | NOTE: Order plastic washers only with plastic breather valve, DO NOT intermix steel and plastic parts.

THRUST WASHER, breather valve - 0.145 thick (80 to Early 82 - FLT, Classic) | NOTE: Order plastic washers only with plastic breather valve, DO NOT intermix steel and plastic parts.

Cam Gear - Late 77 to 84 Big Twins

THRUST WASHER, cam gear

THRUST WASHER cam gear - 0.05 thick

THRUST WASHER cam gear - 0.055 thick

THRUST WASHER cam gear - 0.06 thick

THRUST WASHER cam gear - 0.065 thick

THRUST WASHER cam gear - 0.07 thick

THRUST WASHER cam gear - 0.075 thick

THRUST WASHER cam gear - 0.08 thick

THRUST WASHER cam gear - 0.085 thick

THRUST WASHER cam gear - 0.09 thick

THRUST WASHER cam gear - 0.095 thick

BUSHING, gear cover

BUSHING, gear cover pinion shaft

DRIVE GEAR, oil pump - 24T

DRIVE SHAFT, oil pump

KEY, oil pump gears

DRIVE GEAR, oil pump

COVER inner

COVER, outer

GASKET, ignition cover

Винт

Oil line fitting, rocker arm cover-front - 81 to 84 FLH-80, Classic, FX

Фитинг

OIL SEAL, bearing
