SHOCK ABSORBERS - 1974 & EARLIER

ROLL PIN, 1/8 x 3/8 54 to 72 - KH, XL,XLH, XLCH

SCREW, No. 10-24 x 1 Pozidriv fil. hd. N/A 54 to 64 - KH, XL,XLH

WASHER, 3/8 X 5/8 X 3/64

WASHER, 3/8 X 1 X 5/64

WASHER, 3/8 X 13/16 X 1/16

WASHER, 1-21/32 x 2-15/32 x 3/32 w/2 drilledholes (XLH-low-3) (XLCH 2) 67 to 74 - XLH, XLCH

LOCKWASHER, No. 10

NUT, No. 10-24 X 1/8 X 3/8 hex.(Grade 2 steel)

LOCKNUT, 3/8-24 X 7/16 X 9/16 hex.

HEX NUT, 1/2-20 X 3/4

LOCKNUT, 5/8-18 X 15/16 hex.

UPPER STUD 56 to 74 - KH, XL, XLH, XLCH

STUD, upper 67 to 74 - XLH, XLCH

LOWER STUD 56 to 74 - KH, XL, XLH, XLCH

STUD, lower 67 to 74 - XLH, XLCH

CONVERSION KIT, shock absorber (use w/54490- 78) 67 to 74 - XLH, XLCH | Consists of: 54515-75 STUD, upper; 54516-75 STUD, lower; 54543-65 WASHER, upper - outer; 54545-65 WASHER, ; 54704-75 COVE

CAM SUPPORT 73 & 74 - XLH, XLCH

CAM SLEEVE N/A 67 to 72 - XLH, XLCH

OUTER WASHER, 3/8 dia. hole (4; 2 - upper only -Late 72 to 74) 65 to 74 - XLH, XLCH

INNER WASHER, 5/8 dia. hole 65 to 74 - XLH, XLCH

WASHER, 1/2 dia. hole - lower ; upper - inner Late 72 to 74 - XLH, XLCH

SPRING (chrome) (high road clearance) N/A 73 to 74 - XLH, XLCH

ROTATING CAM, shock absorber 73 & 74 XLH, XLCH

CAM SLEEVE 73 & 74 - XLH, XLCH

DIRT SEAL (67 to 74 - low road clearance) 56 to 64 - KH, XL, XLH, XLCH; 65 to 72 - XLH

RETAINER, SPRING, UPR SHOCK ABS

COVER 67 to 74 - XLH, XLCH

COVER, shock absorber spring N/A 67 to 72 - XLH

COVER, side 65 to 74 - XLH, XLCH

RUBBER BUSHING 54 to 74 - KH, XL, XLH, XLCH
